Bikesrepublic

how to

  • The brakes are often misused – they are not only for stopping.

  • The modern brake systems are there to assist the rider in many ways.

  • But it is the rider who has to use them correctly.

Of all the rider inputs, braking is often the most misunderstood or wrongly performed.

The main reason for this is due to how significant deceleration forces work on the rider’s body, in addition to how his bike’s behavior when the brakes are applied. As such, riders are often confused by how tiny fingers could slow a 300+ kg mass (the combine weight of the motorcycle and rider) from 200 km/h down to 50 km/h in a heartbeat.

1. Use the brakes to set your target speed

Start thinking of the brakes as a tool to help you set your target speed for a corner. For example, if you’ve ridden through your favourite corner on a daily basis, brake and note the speed before you enter the corner. Doing so will allow you to adjust braking point, braking force and entry speed as well as the turn-in point. Too slow through the corner? Apply the brakes later or release sooner. Too fast? Brake earlier or apply more braking pressure.

It doesn’t help to charge into every corner based on “feel” or “mood”. More often than not, too slow a corner entry will force the rider to add too much throttle in mid-corner, thereby risking the tyre breaking traction suddenly. Too fast into a corner will cause the rider to panic and jump on the brakes, causing the front tyre to either break traction and slide under (low-side) or the bike to stand up and head straight toward the outside of the corner (overshoot).

2. Use both brakes

There’s a myth that the rider shouldn’t touch the rear brake pedal unless he’s coming to a stop. Now, unless you’re braking so hard to lift the rear tyre completely off the ground like Marc Marquez, using the rear brake keeps the chassis stable, even if you should feel that using it does not decrease your stopping distance.

If the rear brake is truly defunct in its purpose, why do manufacturers equip their bikes with it in the first place, or lately, the rear-wheel lift mitigation (RLM) electronic rider aid? As the name suggests, it keeps the rear tyre on the ground, allowing the rider to utilize the rear brake. In fact, this rider aid is used extensively in MotoGP (to different degrees among different riders).

Courtesy of Sport Rider

Dragging the rear brake softly while leaned over in a corner helps the bike maintain a tight line. Besides that, it slows the bike slightly without rolling off the throttle or tapping the front brake lever, thus not introducing major abrupt inputs to upset the chassis balance and tyre adhesion.

3. Squeeze, don’t grab

Brakes should be applied progressively (gradually) and not not grabbed or stomped on.

Progressive braking transfers the motorcycle’s and rider’s combined weight progressively to the suspension and tyre. Conversely, abrupt braking causes the wheel to lock. Additionally, mass is slammed forward and eats up suspension travel, causing the front wheel to hop over road irregularities.

If abrupt braking is bad when the bike is straight up, it’s even worse when it’s leaned over on its side. The tyres are already loaded with cornering forces and doesn’t need much more overbraking to overload them. The tyres will either break loose, resulting in a low-side or have the bike standing up and going straight.

So, stop treating the brake levers as ON/OFF switches.

4. Ride loose

Using the arms to support the torso when braking “locks” up the wrists, arms, elbows and shoulders. This in turn means that the rider could only take so much braking forces and gets fooled into thinking that he’s already braking too hard.

Besides that, he would not be able to steer his bike through the corner or out of harm’s way. Ever notice some riders braking hard and still go wide or overshoot a corner?

The trick is to always clamp your thighs onto the fuel tank. That’s the reason why motorcycle designers create knee cutouts (depression) on both sides of the tank. So, clamp your knees onto the tank, and leave your torso and arms as loose (relaxed) as possible. If you’ve never done so during hard braking, you’ll soon discover that you could actually brake so much harder than before, while still being able to steer the bike.

5. ABS helps, not avoid

With all this talk about braking techniques, how does ABS (anti-lock braking system) figure into the equation? Or more accurately, doesn’t ABS take away the need to learn the fundamentals of braking? Oh yes, I’ve had people tell me, “The bike has ABS. The bike will never crash.”

Let’s review what ABS does. Braking is strongest at the point where the tyre is about to break traction. However, that margin between full braking and losing traction is very thin, and once the tyre loses traction, there’s no telling what’ll happen next. When a tyre loses traction, ABS relieves the braking pressure just enough to let the tyre roll then reapply pressure to brake caliper pistons (this happen many times per second).

via GIPHY

That’s all good and nifty. However, riders who are unaccustomed to the brake levers pulsing during ABS activation may actually let go of the levers. So, it all comes back to square one: Learn the basics of braking without intervention.

BONUS TIP: Have faith

Frame, chassis, tyre and brake engineering are so advanced these days; more often than not surpassing the skill levels of the majority of road riders.

This is not a criticism of your riding skills, but it serves as a reminder that the limits of the said components are so high, hence there’s plenty of room to go to save your skin at the time when you thought there’s no hope. The point is, have faith in your tyres, suspension, and bike in general and perform the correct actions when you get into trouble, rather than just giving up and letting fate decide.

Sumber imej: mo-motorcycles-tyres

Artikel oleh: Wahid Ooi Abdullah

  • Tayar adalah cara terbaik bagi menambah baik motosikal.
  • Namun, bagaimanakah anda menentukan tayar yang terbaik?
  • Di sini kami senaraikan beberapa perkara yang perlu dipertimbangkan beserta tip.

(more…)

  • Tyres are the best way to improve your bike.

  • But how do you determine the best tyres?

  • Here are a few points to consider plus tips.

We’re overstating the obvious here, but tyres are definitely the most important component on your motorcycle. Tyres not only determine the bike’s handling, but also translates to rider safety, confidence, comfort, and fuel consumption in the overall picture.

But what are the factors you should base your choice on?

COMPROMISE

Do realise that all tyres are a compromise between mileage vs. wear, slow-speed vs. high-speed handling, stability vs. quick-turning, and many more aspects. A tyre that is popular in racing championships such as MotoGP and World Superbike may not suit your riding style or the mileage you have in mind.

That’s because different brands and even the models offered by one brand have different characteristics. For example, Bridgestones generally have hard sidewalls and round profiles compared to Metzelers and Pirellis that have softer sidewalls and round profiles. However, while the Pirelli Supercorsa ‘s profile is rounded, the Pirelli Angel ST sport-touring tyre is triangulated.

Firm sidewalls provide lots of feedback to the rider, but may not provide the confidence and comfort to some riders when the road gets bumpy. Conversely, soft sidewalls are more compliant, thereby providing more confidence over bumps at the expense of some feedback.

Furthermore, certain tyres are made to slide early as a signal to rider who’s nearing the limit (although there’s still much traction left). I personally like this characteristic because I don’t have to second guess the tyres’ limits, especially when riding in the rain or on wet roads. Certain riders may find it disconcerting or terrifying to have their tyres sliding around.

PROFILES

A triangulated profile gives the sensation of quick steering and willingness to lean into a corner. Additionally, a triangulated profile provide better side grip due to bigger contact patches. However, these type of tyres may not feel as stable when riding in a straight line and hard braking.

A round profile tyre offers more stability when running straight and during hard braking, sacrificing quick turning and flickability, hence feeling more neutral. Besides that, round profile tyres allow the rider to maintain his chosen line with comparative ease.

Again, the question: Which one?

It depends on your riding style, preference (read: brand) and skill level. My personal choice is the triangulated profile as I like the extra agility when commuting. But it’s also because of my preference to turn into corners later on the streets (to allow me to see further through corners), which requires me to flick the bike in quickly. Conversely, I prefer the round profile tyre on the track where the corners are set in place and since there’s no need to cilok through traffic.

COMPOUNDS

One undying tyre myth is that stickier race tyres allows riders to go faster. While this certainly applies to the track, it isn’t so on the streets.

As most already know, rubber becomes more pliable when it’s heated up, allowing it to conform to the “peaks” and “valleys” in the road surface. This heating and cooling cycles also alter the tyre’s character, turning the compound harder and harder over time.

Race tyres are made just for that: Racing. They perform at their optimum levels once or twice and then discarded. Race tyres are also designed to withstand more heat due to the extreme speeds; cornering, acceleration and braking forces; and abrasion before they finally degrade. For this reason, they need more time and aggressive riding to get them up to working temperature.

That in turn makes them unpractical for street use, as riding like a madman everywhere is just plain impossible, not to mention dangerous even if one is able to.

Besides that, dry race tyres don’t have much tread or even at all to handle rain, or other dirty conditions on public roads. Wet weather racing tyres on the other hand uses ultra-soft compound that’ll destroy itself in less than 60 km when ridden in the dry.

In this case, you should just go ahead and fit street compound tyres that’ll provide good mileage and still could be occasionally used on the track. As we discussed above, street compound tyres need very little time and aggressive riding to get them working properly.

Tyre technologies have advanced so much that even sport-touring tyres provide better grip for 90% of all the riders out on the streets. The Bridgestone T30 Evo, Pirelli Rosso Corsa, and Pirelli Angel ST, Michelin Pilot 4 are pretty good examples. You’d be surprised what some skilled riders could do with these tyres. Let’s be honest with ourselves here. Most of us couldn’t outride the capabilities of modern sport-touring tyres.

On the other hand, it’s not wrong to fit supersport tyres if that’s your cup of tea. However, do consider if your riding or intended riding consists mostly of daily commuting on the highway, with just the occasional weekend lemang ride and rarely to never on the track. It may make more sense if commute between Ulu Yam and the city, but how about rainy days?

TYRE AGE

A tyre’s production date is stamped on the sidewall and you may see something like “3017.” The first two digits denote the production week, while the last two denote the year. In this case, the tyre was produced on the 30th production week in 2017.

Never buy tyres that are six years old or more, including second hand ones.

Speaking of used tyres, I’ve met riders who complained that their used tyres were terrible and couldn’t understand why many other riders swear by them.

Remember the earlier discussion about heat cycles? It’s safe to assume that second hand tyres have gone through a few heat cycles before being put up for sale. The chemicals in the tyre will “outgas” leaving behind a tyre that’s pretty much unlike a fresh tyre anymore, despite looking new and has deep treads.

Apart from that, because each rider has a different riding style or skill, a tyre will take on the characteristics as the direct result. Yes, you may say that tyres have “memory.” This is also one of the few reasons why we feel “different” on a friend’s identical bike.

Again, it’s not wrong to use second hand tyres, but do not compare them to how they would be when new.

BREAKING IN NEW TYRES

Breaking in, or running in, new tyres should be done with some thought.

A tyres need a few repeated heating and cooling cycles to stabilize its chemical compounds. Additionally, how you break in a tyre will determine how it would perform further into its life. Too much stress early in a tyre’s early life will have it hardening quicker. As such, don’t be too gentle or greedy in breaking in your tyres during the initial 300 km.

TYRE PRESSURE

Sometimes manufacturers would overinflate the tyres of the bikes leaving the factory for storage and transportation. There are dealers who don’t check for this when they deliver the bikes to customers, leading the new owners to believe that new tyres should be overinflated.

Truth is, it’s always best to refer to the bike manufacturer’s recommended pressures. (Ironic, eh?) We’ve posted this question directly to Pirelli during a recent Pirelli tyre clinic and they recommended so as well.

You may increase the tyre pressures when carrying a passenger and luggage, but again, your motorcycle manufacturer has recommendations for these scenarios. Just fill up according to the pressures usually stated on the swingarm for the respective scenarios.

Sumber imej: Visordown

Artikel oleh: Wahid Ooi Abdullah

  • Di sini kami senaraikan beberapa tips bagaimana untuk menunggang meredahi banjir kilat (atau kawasan air dalam).
  • Peraturan yang paling utama adalah bergerak dengan perlahan.
  • Kawalan pendikit dan tenang menghadapi rintangan juga sangat penting.

(more…)

  • Here are tips on how to ride through flash floods (or deep water)

  • Cardinal rule is to go slow

  • Throttle control and a cool head applies

The weather has been mighty unpredictable in the Klang Valley lately. The days invariably start with burning white sunlight and scorching heat, only to give way to sudden heavy downpours. If the downpours continue for more than two hours, we could find ourselves  caught in flash floods.

Courtesy of Astro Awani

While it’s safest to sit out from riding in pouring rain and flooded roads, there’s no escaping it at times, especially around flood-prone areas where the roads remain flooded even after rain has stopped.

Here are our tips for riding through flash floods (and deep puddles of water).

1. Stop and Inspect

It’s just like adventure riding. No sane adventure rider will just banzai headlong into an unknown body of water without first inspecting its depth, potential hazards underwater and exit on the other side.

While you may not have to get off your bike and walk through floods on the road you travel on each day, you do need to stop and look for clues. If there’s another vehicle pushing through the water, note how deep it is. Observe if there’s a strong water current from one side of the road to the other.

If the water’s too deep or current’s too strong, forget it. Just wait for it to subside.

If you don’t already know the location of your engine’s air intake, now’s the good time to start. Check if it’s high enough above the water.

2. Stand Up

Riding through floods is no different from riding through a river when adventure or trail riding, so stand for better low-speed stability, meaning there’s more control when you crawl ahead at 10 to 20 km/h.

Courtesy of twistedthrottle

3. Go Slow and Straight

This goes without saying.

Throwing up a big splash may look spectacular in pictures but it isn’t a good practice in real world situations. Hitting a deep body of water at speed would most likely have the water act as a liquid brake/barrier. The bike will cut through the first few metres easily before coming to a sudden halt and causing the rider to lose control (or even thrown off).

They need to go a little slower than this. Courtesy of thestar

Keep your speed as low as possible and steady to keep the water’s bow wake below the height of the engine’s air intake. Remember, you’re riding a motorcycle, not a jetski.

It’s also best to stay off the sides of the road and ride in the middle of the lane.

4. Keep Moving

Don’t pull in the clutch or slam the throttle shut.

Maintain a steady throttle and speed in the gear you are in right now, even if you should feel a tyre or tyres kicking loose when contacting something in the water. In fact, you should open the throttle a bit more if that happens.

Courtesy of visordown

Roll off the throttle smoothly if you need to slow down more and stay off the brakes.

5. Exiting

Don’t gun it immediately after exiting the flood. You may increase your speed, but don’t slam open the throttle, without first giving the time for the water or whatever debris collected on the bike to “drop off.”

Also, with the bike still moving, drag the brakes lightly to clean them.

Courtesy of ultimatemotorcycling

6. Kill It!

But what if you hit, for example, a pothole and the bike goes down?

Make the effort to kill the engine before you lay the bike down into the water. You’d most probability have the time to do so, since you were riding at a slow speed, right? Right? Regardless, the engine should be shut down as quickly as possible.

Courtesy of smugsmug

An internal combustion engine is basically an air pump which sucks in air, adds fuel to it, compresses the mixture and sets it alight. But water is incompressible and non-combustible (duh!), and therefore has the potential of causing catastrophic engine damage.

Do not immediately attempt to start a motorcycle that has been lying underwater. Instead, you should pull out the spark plugs and the airbox cover to check for water ingress. If the spark plug electrodes are wet, do not reinstall them, but turn on the bike’s ignition and crank the starter a few times to push the water out of the combustion chamber.

Reinstall only when it’s sufficiently dry.

Conclusion

Riding through a flood isn’t difficult but one should do it with care and logic, obviously. Sticking to the above steps will have you home way ahead of car drivers, instead of ending up swimming in that filthy water. Think of it as urban adventure riding.
